Spesifikasi G M/T
Dimension
| Overall Panjang / Length (mm) | 4.110 | 4.110 | 4.110 |
|---|---|---|---|
| Overall Lebar / Width (mm) | 1.655 | 1.655 | 1.655 |
| Overall Tinggi / Height (mm) | 1.600 | 1.600 | 1.600 |
| Jarak Poros Roda / Wheelbase (mm) | 2.525 | 2.525 | 2.525 |
| Jarak Pijak Depan / Front Tread (mm) | 1.460 | 1.460 | 1.460 |
| Jarak Pijak Belakang / Rear Tread (mm) | 1.465 | 1.465 | 1.465 |
| Jarak Terendah / Ground Clearance (mm) | 180 | 180 | 180 |
| Overhang Depan / Front (mm) | 630 | 630 | 630 |
| Overhang Belakang / Rear (mm) | 915 | 915 | 915 |
Engine
| Tipe Mesin / Engine Type | 3NR-VE(1,2L) | 3NR-VE(1,2L) | 3NR-VE(1,2L) |
|---|---|---|---|
| No. Of Cyls & Arrangement | In-line 4 Cylinder, 16 Valve, DOCH, Dual VVT-i | In-line 4 Cylinder, 16 Valve, DOCH, Dual VVT-i | In-line 4 Cylinder, 16 Valve, DOCH, Dual VVT-i |
| Isi Silinder / Displacement (cc) | 1.197 | 1.197 | 1.197 |
| Torsi Maksimal / Maximum Torque (kgm/rpm) | 11/4.200 | 11/4.200 | 11/4.200 |
| Daya Maksimal / Maximum Power (ps/rpm) | 88/6.000 | 88/6.000 | 88/6.000 |
| Bahan Bakar / Fuel Type | Bensin / 4 Silinder Sejajar | Bensin / 4 Silinder Sejajar | Bensin / 4 Silinder Sejajar |
Chassis
| Sistem Penggerak Roda / Drive System | Front Wheel Drive | Front Wheel Drive | Front Wheel Drive |
|---|---|---|---|
| Transmisi / Transmission | 5MT | 5MT | 4AT |
| Diameter x Langkah / Bore x Stroke (mm x mm) | 72,5 x 72,5 | 72,5 x 72,5 | 72,5 x 72,5 |
| Perbandingan Gigi / Gear Ratio (1st) | 3.417 | 3.417 | 2.731 |
| Perbandingan Gigi / Gear Ratio (2nd) | 1.960 | 1.960 | 1.526 |
| Perbandingan Gigi / Gear Ratio (3rd) | 1.250 | 1.250 | 1.000 |
| Perbandingan Gigi / Gear Ratio (4th) | 0,917 | 0,917 | 0,696 |
| Perbandingan Gigi / Gear Ratio (5th) | 0,707 | 0,707 | |
| Perbandingan Gigi Mundur / Reverse Gear Ratio | 3.143 | 3.143 | 2.290 |
| Perbandingan Gigi Akhir / Final Gear Ratio | 5.077 | 5.077 | 4.839 |
| Sistem Kemudi / Steering System | Electronic Power Steering (EPS) | Electronic Power Steering (EPS) | Electronic Power Steering (EPS) |
| Suspensi Depan / Front Suspension | MacPherson Strut with Coil Spring and Stabilizer | MacPherson Strut with Coil Spring and Stabilizer | MacPherson Strut with Coil Spring and Stabilizer |
| Suspensi Belakang / Rear Suspension | Semi Independent Torsion Axie Beam with Coil Spring | Semi independent Torsion Axie Beam with Coil Spring and Stabilizer | Semi independent Torsion Axie Beam with Coil Spring and Stabilizer |
| Tipe Rem Depan / Front Brake Type | 13 DISK(22V,VENTILATED) | 13 DISK(22V,VENTILATED) | 13 DISK(22V,VENTILATED) |
| Tipe Rem Belakang / Rear Brake Type | DRAM:200 | DRAM:200 | DRAM:200 |
| Sistem Parkir / Parking System | PKSA(O/RR2) | PKSA(O/RR2) | PKSA(O/RR2) |
| Rem Parkir / Parking Brake | C/L(W/S-BUTTON (PLATING)) | C/L(W/S-BUTTON (PLATING)) | C/L(W/S-BUTTON (PLATING)) |
| Ukuran Ban / Tire Size | 175/65 R14 | 175/65 R14 | 175/65 R14 |
| Ban Cadangan / Spare Tire | With GRAND-TIRE(AL) | With GRAND-TIRE(AL) | With GRAND-TIRE(AL) |
